Specification:

Size: 10V14~20BB24 (Inlet size: 10"~20", outlet size: 14"~24")

Pressure: 150LB~300LB

Main Parts Material:

Body Material:  Carbon Steel, Low Carbon Steel, Chrome Molybdenum Steel, Austenitic Stainless Steel etc.

Nozzle: 304, 316, 304L, 316L, HC, HB, Monel etc.

Disc: 304, 316, 304L, 316L, HC, HB, Monel etc.

Spring: Alloy Steel

Spindle: 420

Bellows: 316L

Temperature: -196℃~538℃

The allowable tolerance of the set pressure: ≤±3%；

Over pressure: ≤10% of the set pressure;

Blow down: ≤10% of the set pressure;

Tightness: the valves have good seat tightness, conforms to API527.
